Quick Details
- Light Source: LED
- Item Type: Flood Lights
- LED Light Source: USA Bridgelux/Cree/Genesis
- Input Voltage(V): 100-277
- Lamp Power(W): 120
- Lamp Luminous Flux(lm): 12000
- Lamp Luminous Efficiency(lm/w): 100
- CRI (Ra>): 70
- Color Temperature(CCT): Cool White
- Beam Angle(°): 120
- Working Temperature(℃): -40 - 50
- Working Lifetime(Hour): 100000
- Lamp Body Material: Aluminum Alloy
- IP Rating: IP68
- Certification: C-tick, CCC, CE, CQC, EMC, FCC, LVD, PSE, RoHS, SAA, UL
- Place of Origin: Guangdong, China (Mainland)
- Brand Name: CESP
- Model Number: IP68 UL ATEX 120w explosion proof led floodlight
- Name: IP68 UL ATEX 120w explosion proof led floodlight
- certifications: CE ROHS CUL UL DLC CNEX ATEX SAA
- water proof: ip68
- Material: Die cast aluminum alloy
- Power driver: Meanwell HLG driver ( The best)
- Efficacy: 90-100lm/w
- Application: hazardous area lighting
- Driver: Meanwell HLG
- PF: 0.98
- Life: 100000 hours
Packaging & Delivery
| Packaging Details: | IP68 UL ATEX 120w explosion proof led floodlight
1set/carton in foam and cartons, standard carton outside carton size: 460x460x240mm G.W.: 12.5kgs N.W.:11.5kgs |
|---|---|
| Delivery Detail: | Shipped in 7 days after payment |
IP68 UL ATEX 120w explosion proof led floodlight
Why CESP?
1. For hazardous area lighting products like GAS STATION LED CANOPY LIGHTS, it is fairly important to choose specialized manufacturer because the security for hazardous area lighting is essential.
2. CESP is a specilized LED EXPLOSION PROOF LIGHT manufacturer in the passed 8 years, with CE/ROHS/UL/CUL/DLC/SAA/PSE certification, and most important, ATEX and CNEX explosion proof certification.
3. Besides, we'll soon get the UL844(class 1 division 2) explosion proof certification, which means we'll be the only manufacturer who owns these qualifications at the same time.
4. By now we have a whole series LED CANOPY LIGHTS (CES-J), including 20W-185W wide power range and various installation brackets, and also customizable product color. can satisfy most of the hazardous area lighting applications.
Key features;
-Die-cast aluminum by 1800 Ton of pressure to make the body strong enough.
-Powder Coated (similar to vehicles coating) and holder are cover with a thin layer of Zink, color can be ---customizable.
-IP 68, highest rating of protection.
-Anti- flame, high quality water proof silicon, 4MM super-strength tempered glass.
-5 year warranty.
-Best driver: Meanwell HLG driver.
Main Technology | |
LED Chips: | BridgeLux LED chips packaged professionally ensure the light source kept in optimum performance; mirror surface processed technology collect and reflect the invalid light into efficiency; use of lens controls the horizontal and vertical beam angle actively. |
Power Supply: | To use world’s leading brand MeanWell power supply ensure the fixture works in stableness with better performance and enjoy its long life; power supply is CE RoHS TUV CB certificated. |
Housing | High pressure intergrated die cast aluminum, perfect protection |
Specification:
Item No | Product Specification | Certificate for Europe | Certificate for US&Canada | ||||
Rated Power | Size(mm) | With reflector(RF) or not | Beam | IP | |||
Angle | Rating | ||||||
CES-J200 | 185W | 400*400*185mm | NO | 120°x120° | IP68 | CE/ROHS | UL/CUL/DLC |
CES-J150 | 150W | 400*400*185mm | NO | 120°x120° | IP68 | CE/ROHS | UL/CUL |
CES-J120 | 120W | 400*400*185mm | Optional | 60°x30°(RF) | IP68 | ATEX/CE/ROHS | UL/CUL |
CES-J100 | 100 | 300*300*175mm | NO | 120°x120° | IP68 | ATEX/CE/ROHS | UL/CUL/DLC |
CES-J80 | 80W | 300*300*175mm | Optional | 60°x30°(RF) | IP68 | ATEX/CE/ROHS | UL/CUL |
CES-J40S | 40W | 200*200*270mm | Optional | 60°x30°(RF) | IP68 | ATEX/CE/ROHS | UL/CUL/DLC |
LED Specification | Driver Specification | |||||||||
Item No. | LED QTY | Lumens | Lumen | CCT | CRI | Input V | Input Current | PF | THD | Type |
Lm/W | ||||||||||
CES-J200 | 156 pcs | 16550 | 90Lm/W | Cool White: 5700-6500K | >70 | AC100-277V | 350mA | >0.98 | <10% | HLG MEANWELL driver with IP68 protective Aluminum Housing |
CES-J150 | 144 pcs | 13500 | 90Lm/W | >70 | AC100-277V | 350mA | >0.98 | <10% | ||
CES-J120 | 96 pcs | 10800 | 90Lm/W | Natural White: 3700-4500K | >70 | AC100-277V | 350mA | >0.98 | <10% | |
CES-J100 | 84 pcs | 9000 | 90Lm/W | >70 | AC100-277V | 350mA | >0.98 | <10% | ||
CES-J80 | 60pcs | 7200 | 90Lm/W | Warm White: 2700-3500K | >70 | AC100-277V | 350mA | >0.98 | <10% | |
CES-J40S | 24pcs | 3600 | 90Lm/W | >70 | AC100-277V | 350mA | >0.98 | <10% | ||
Product image:
Certification:
Application:
Widely used in gas station led canopy lighting , oil refinery industrial lighting , coal mine lighting and explosion proof flood lighting etc.
Factory show:
