Quick Details

  • Light Source: LED
  • Item Type: Explosion-proof Lights
  • LED Light Source: Bridgelux
  • Input Voltage(V): AC100-277V, 100-277V
  • Lamp Power(W): 100
  • Lamp Luminous Flux(lm): 11000
  • Lamp Luminous Efficiency(lm/w): 110
  • CRI (Ra>): 80
  • Color Temperature(CCT): Pure White
  • Working Temperature(℃): -40 - 50
  • Working Lifetime(Hour): 50000
  • IP Rating: IP68
  • Certification: CCC, CE, EMC, ETL, LVD, PSE, RoHS, SAA, UL, VDE
  • Emitting Color: White
  • Base Type: U bracket
  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: CESP
  • Model Number: CES-J100
  • certifications: CE ROHS CUL UL DLC CNEX ATEX SAA CQC FCC PSE
  • led: USA Bridgelux/cree/genesis
  • water proof: Ip68, 5 years Warranty
  • Material: Die cast aluminum alloy
  • Power driver: Meanwell HLG driver ( The best)
  • Efficacy: 110lm/w
  • Application: Zone 1
  • Type: Explosion-proof Lights
  • housing: ADC12 die cast aluminum alloy

Packaging & Delivery

Packaging Details 1set/carton
in foam and cartons, standard carton
outside carton size: 460x460x240mm
G.W.: 12.5kgs
N.W.:11.5kgs

UL844 class I division2, ATEX, CE, Rohs, CQC, CUL, DLC, ETL, CETL, Lm80, Lm79, SAA, C-tick, PSE, ISO 9001, ISO 14001,CNEX explosion proof LED light  20W-185W









 Key features:

 -Die-cast aluminum by 1800 Ton of pressure to make the body strong enough.

- tested strictly: waterproof test, photometric test, high temperature simulated environment test, salt spray corrison test, vibration test, lighting protection, leak-proof test, dust-proof & oil-proof teste.

-IP 68, highest rating of protection.

-Anti- flame, high quality water proof silicon, 4MM super-strength tempered glass.

-5 year warranty.

-Best driver: Meanwell HLG driver.



Main Technology

LED Chips:

BridgeLux LED chips packaged professionally ensure the light source kept in optimum performance; mirror surface processed technology collect and reflect the invalid light into efficiency; use of lens controls the horizontal and vertical beam angle actively.

Power Supply:

To use world’s leading brand MeanWell power supply ensure the fixture works in stableness with better performance and enjoy its long life; power supply is CE RoHS TUV CB certificated.

Heat Dissipation:

LEDs combined with aluminum radiator directly and closely make the LEDs have better performance of heat dissipation; sufficient area of aluminum radiator and full range air permeability of the fixture reduce the optical attenuation and control LEDs failure.





Specification:



   Item No

                                                  Product Specification

Certificate

for Europe

Certificate for

US&Canada

Rated Power

Size(mm)

With reflector(RF)

or not

Beam

IP

Angle

Rating

CES-J200

185W

400*400*185mm

NO

120°x120°

IP68

CE/ROHS

UL/CUL/DLC

CES-J150

150W

400*400*185mm

NO

120°x120°

IP68

CE/ROHS

UL/CUL

CES-J120

120W

400*400*185mm

Optional

60°x30°(RF)
/120°x120°

IP68

ATEX/CE/ROHS

UL/CUL

CES-J100

100

300*300*175mm

NO

120°x120°

IP68

ATEX/CE/ROHS

UL/CUL/DLC

CES-J80

80W

300*300*175mm

Optional

60°x30°(RF)
/120°x120°

IP68

ATEX/CE/ROHS

UL/CUL

CES-J40S

40W

200*200*270mm

Optional

60°x30°(RF)
/120°x120°

IP68

ATEX/CE/ROHS

UL/CUL/DLC







                    LED Specification

                       Driver  Specification

Item No.

LED QTY

Lumens

Lumen

       CCT

  CRI

     Input V

Input Current

   PF

THD

              Type

Lm/W

CES-J200

156 pcs

16550

90Lm/W

Cool White:

5700-6500K

>70

AC100-277V

350mA

>0.98

<10%

HLG MEANWELL driver

with IP68 protective

Aluminum Housing

CES-J150

144 pcs

13500

90Lm/W

>70

AC100-277V

350mA

>0.98

<10%

CES-J120

96 pcs

10800

90Lm/W

Natural White:

3700-4500K

>70

AC100-277V

350mA

>0.98

<10%

CES-J100

84 pcs

9000

90Lm/W

>70

AC100-277V

350mA

>0.98

<10%

CES-J80

60pcs

7200

90Lm/W

Warm White:

2700-3500K

>70

AC100-277V

350mA

>0.98

<10%

CES-J40S

24pcs

3600

90Lm/W

>70

AC100-277V

350mA

>0.98

<10%



Product image:















Certification:









Application:







Factory;











Shenzhen CESP is the largest production base for LED Explosion proof lights in China, who is also the first company to get UL844 certificate in China, please contact me for more info.
