high power LED gas station light 120W / led tunnel light

FOB Reference Price:Get Latest Price
US $300-345 / Pieces | 5 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Light Source:
LED
Item Type:
Tunnel Lights
LED Light Source:
Bridgelux /CREE
Input Voltage(V):
AC85-265V
Lamp Luminous Flux(lm):
11160
CRI (Ra>):
80
Working Temperature(℃):
-40 - 50
Working Lifetime(Hour):
50000
IP Rating:
IP68
Certification:
CE, Energy Star, ETL, RoHS, UL
Warranty(Year):
5
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
CESP Spirit Lighting
Model Number:
CES-J120
Color:
White
Rated Power:
40~120W
LED Type:
Bridgelux / CREE
Protection Level:
IP68
Voltage:
85-265V
LED Qty:
120pcs
Lifespan:
50,000H
Warranty:
5 years
THD:
<10%
PF:
~0.98
Color Temperature(CCT):
Cool White
Lamp Power(W):
120
Lamp Body Material:
Aluminum Alloy
Lamp Luminous Efficiency(lm/w):
93
Supply Ability
Supply Ability:
10000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
in foams and cartons
Port
Shenzhen
Lead Time :
15 days after payment received

Specifications

IP68, 50000~100000H lifespan
UL/DLC/ATEX/CE approved
input AC85-265V
Bridgelux/CREE chip LED
Die-casting aluminum housing






















*actual product may vary from picture show.

LED Anti Explosive Light

Wall Mount



DIMENSIONS

LENGTH :  400mm

WIDTH :   400mm

HEIGHT :  185mm

WEIGHT:  11.5 KG





LED LIGHT ENGINE

  • Cree XPE  Group R3

(XPEWHT-L1-0000-00F01)

  • Efficacy : up to 122lm @ 350Ma (per watt)
  • Rated Life of 100,000+ hrs
  • Operation temp: -30 ºC to +50 ºC
  • No toxic chemicals/Rohs compliant
  • 70%-80%  saving compare to HPS/MH



PRODUCT FEATURE

  • 5 years warranty
  • Highest Ingress Protection rating : IP68









Note

ITEM NO.

DESCRIPTION

TOTAL POWER

Reflector/ wide angle

NOMINAL LUMENS

DRIVE CURRENT

# OF LEDS

SYSTEM  EFFICACY

UL/CUL/ CE Certify

CES-J120

Replacing 400-500w HPS

120

Optional for both

9240

350 mA

96

77 LM/W

*Total power consumption may vary due to installation location.





Perfection is the Goal



APPEARANCE

  • Material:   Die Cast Aluminum
  • Light Color option:  Cool White

Warm White

Custom color

  • LENS:  Super Clear Tempered Glass



ELECTRICAL CHARACTERISTICS

  • Wide AC input:  90-305 VAC
  • (UL marking: 100-240VAC/277VAC)
  • Power Factor: ~0.98
  • Total Harmonic Distortion: < 10%
  • Surge protection: IEC/EN 61000-4-5
  • EMC test standard





  INSTALLATION

  • Easy installation  plug and play
  • Wall Mount bracket



QUALIFICATION

  • CE: Recognition with CNAS
  • ISO 14001: Recognition with IAF & CNAS
  • ISO 9001: Recognition with IAF & CNAS
  • UL & CUL Certify : ANSI/UL 1598 & ANSI/UL 8750
