ATEX UL listed 5 years warranty 100W explosion proof tunnel light IP67

FOB Reference Price:Get Latest Price
US $100-400 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Item Type:
Tunnel Lights, Tunnel Lights
Input Voltage(V):
100-277
Lamp Luminous Flux(lm):
11500
Lamp Luminous Efficiency(lm/w):
115
CRI (Ra>):
73
Color Temperature(CCT):
Cool White
Working Temperature(℃):
-40 - 50
Working Lifetime(Hour):
100000
Lamp Body Material:
Aluminum Alloy
IP Rating:
IP67
Certification:
CE, EMC, LVD, PSE, RoHS, UL, ATEX UL CE DLC RoHS
Place of Origin:
Guangdong, China (Mainland)
Model Number:
J100
LED Type:
Bridgelux 3030
Driver:
Taiwan Meanwell HLG Series
Housing:
Die-casting Aluminum ADC 12
LENS:
Super Clear Tempered Glass
PF:
98%
THD:
<10%
Warranty(Year):
5
Lamp Power(W):
100
Supply Ability
Supply Ability:
50000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
one in a carton, filled in foam ;
Dimension of the carton: 370*370*240mm
Port
Shenzhen
Lead Time :
12 days upon payment

ATEX UL listed explosion proof tunnel Light IP67

Certification

DLC/UL/CUL/CE/ROHS/ATEX

Material of shell

Die Cast Aluminum,Temper Glass,Anti-Dust,

Water-proof,PCB Heat Index 2.0, with reflector

Working Temperature

-40°C to 50°C

Size

300*300*185mm

warranty

5 years for whole lamp/15 years for housing

Beam Angle

60°x30°(RF) / 120°x120°

IP Rating

IP67

LED Brand

84pcs Bridgelux

Lumens

11500

Lm/W

115Lm/W

CCT

5700-6500K

Input V

AC100-277V

PF

~98%

THD

<10%

Power Type

HLG MW driver with

protective Aluminum Housing

outside carton size

370x370x240mm

G.W

9kgs

N.W

8.5kgs



















































 ATEX certification.jpgAnti-fire silicon (1).png









 1396939096611_hz-fileserver-upload-03_239376601396938378686_hz-fileserver-upload-03_23919643

 IP68 waterproof.jpgDSC_0035.jpgDSC_0023.jpg




Company Information

 atex led light.pngexplosion-proof light.jpg

led canopy lihgt for gas station.jpg
We are a explosion proof led light manufacturer in China, Award by Central Government "National High Tech Enterprise",  with ATEX(Official Anti Explosive Certification),  suitable to use in coal mining, oil&chemical processing, petroleum,natural gas, military..etc.

1,differentiation advantage, can be use for special lighting, special is always the engine of business

2, high tech advantage, with 5 years warranty, 24 hours successive working, life-span:> 100.000 hours, when touch it , no heating feeling, 75-80% saving compare to HPS, driver is meanwell driver come from Taiwan factory better then Guangzhou factory by experience, housing is patented part, integrated die cast aluminum, gapless, suction cup seal with double protection, the highest ip68, put into water working 6 days for test was safe and sound,15 years warranty for housing

3, Low-cost, in this quality grade, the quotation is very resonable. you even don't need much cost, don't need have our products in stock, if you have that customers, can supply directly from China.

4,market protection,  if you represent this products, you will be the only one in your area that is able to have this patent  and certification, you can put our products into your website even put your logo on it.

Did you ever have that customers want long time warranty or have a high requirement about waterproof and corrosion protection, Do you want to give up this market to your competitors?
