in foam and cartons
outside carton size: 460x460x240mm
IP68 waterproof 80watt ATEX approval LED explosion proof light
- Die-cast aluminum by 1800 Ton of pressure to make the body strong enough.
- Powder Coated (similar to vehicle’s coating) and holder are cover with a thin layer of Zink, color can be customizable.
- IP 68, highest rating of protection.
- Anti- flame, high quality water proof silicon, 4MM super-strength tempered glass.
- 5 year warranty.
- Best driver: Meanwell driver.
Total Power Consume
Whole Fixture Lumen
Bridgelun or Cree
Equal to HPS 400-500w
Color Rendering Index
Warm White: 2700K-4000K
Cool White: 5500-6500K
Meanwell HLG Series
Die Cast Aluminum
Anti Explosive: Class E – Gas filled environment- ExemⅡT6 Gc e class
USA Bridgelux chip or Cree chip
LED Life Span
ADC12 high thermal conductivity material, anti-dust thermal conductivity coatings
Protection screen material
4mm(thickness) toughened glass
Qty per Carton:
1 Unit / Carton
Central Lux (lx)
Average Cover (M)
BridgeLux LED chips packaged professionally ensure the light source kept in optimum performance; mirror surface processed technology collect and reflect the invalid light into efficiency; use of lens controls the horizontal and vertical beam angle actively.
To use world’s leading brand MeanWell power supply ensure the fixture works in stableness with better performance and enjoy its long life; power supply is CE RoHS TUV CB certificated.
LEDs combined with aluminum radiator directly and closely make the LEDs have better performance of heat dissipation; sufficient area of aluminum radiator and full range air permeability of the fixture reduce the optical attenuation and control LEDs failure.
1). Original the superconducting heat ADC12 die-cast aluminum arc heat sink system, exponentially increase the natural cooling area, and has super air convection cooling function, effectively extending the lamp life and improve the use of performance.
2). Original designed die casting lamp shell completely closed, and the use of high-performance waterproof and fireproof silicone, protection grade IP68 waterproof anti-leakage effectively prevent the failure occurred, safe and reliable.
Experienced production team and quality control team make sure the better quality.
3). Unique heat sink wash tank design and anti-dust, anti-corrosion material, make lamp shell has a self-cleaning function, effectively prevent the accumulation of dust, grease, to protect lighting performance.
4). Original second optical design of the the integrated overall mirror condenser Cup and diamond-shaped reflector cone, utilized the light energy and greatly enhanced lighting effects.
5). Gas station lights, tunnel lights, stadium lights series by the Chinese explosion-proof certification, and has passed CE, ROHS certification.
